belt driven tm45 hobby metal working mill drill machine

Shanghai Sumore Industrial Group
Contact Now

belt driven tm45 hobby metal working mill drill machine

Place of Origin : China

Brand Name : Sumore

Certification : CE

Model Number : ZAY7020

use : belt driven hobby metal working mill drill machine

Contact Now

belt driven hobby metal working mill drill machine



Specifications

model                       ZAY7020       ZAY7032        ZAY7040     ZAY7045

drilling capacity                 20mm                32mm                    40mm               45mm

end milling capacity           20mm                20mm                    32mm               32mm

face milling capacity          63mm                63mm                    80mm               80mm

headstock travel(Z)           80mm               130mm                 130mm              130mm

cross axis(Y)                    140mm              175mm                 175mm              175mm

longitudinal axis(X)           290mm              500mm                 500mm              500mm

throat                                181mm              450mm                 450mm             450mm



table  size                        520X160mm   800X240mm         800X240mm     800X240mm



column horizontally angle                                 360 degree

motor power                     550W              1500W                   1500W               1500W       spindle speed             100-2200rpm      80-2080rpm          80-2080rpm     80-2080rpm

packing size            620*750*1000mm     1020*820*1000mm       1020*820*1000mm 1020*820*1000mm

weight                             190kg                330kg                    333kg                  333kg









Company Information

As you can see from Alibaba ,we have been in this field for over 10 year .Now we supply a wide range of  lathe, mill , drill  , CNC and other tools for hobby and industrial market with different specifications and prices for your choice.If any need , please contact us dirctly at shenlong@sumore.com.



FAQ

All the parameters are for reference .We reserve the rights to change before further notice .Anything , please consult our sales department.
